Custom Titanium Electrode
مقدمة
- This pure titanium plate electrode is manufactured from high‑quality Grade 1 or Grade 2 titanium, offering excellent corrosion resistance, low weight, and good mechanical strength. It can be used as either anode or cathode in water electrolysis, electroplating/electropolishing, seawater and wastewater treatment, electrolytic cleaning, and a wide range of laboratory electrochemical cells. The flat plate design ensures uniform current distribution and easy installation in both parallel‑plate and tubular reactors, and it can also serve as a robust current collector or substrate for various catalytic coatings.
-
All parameters are customizable, including titanium grade, thickness, length, width, surface finish (pickled, brushed, polished), and edge treatment (rounded, drilled, framed, or welded). Plates can be supplied as rectangular, square, round or special‑shaped electrodes according to drawings. Optional welded tabs, busbars, mounting holes, and insulated sections are available to match your power connection and reactor design, making this pure Ti plate electrode a flexible solution for both R&D and industrial electrochemical applications.
المواصفات
| النوع | Titanium Electrode |
| Material Grade | Gr1 / Gr2 / Gr7 / Gr9 titanium, other grades on request |
| النقاء | ≥99.99% |
| نموذج | Expanded mesh, perforated mesh, woven wire mesh; supplied as flat sheet, panel, or roll |
| السماكة | Mesh thickness or wire diameter customizable (typ. 0.1–1.0 mm), as per request |
| Mesh Size & Shape | Mesh opening size, strand width, and pattern fully customizable; rectangle, square, round, ring, plate, and special-shaped as per drawing |
| Surface Finish | Pickled, sandblasted, brushed, polished, or as‑rolled surface, depending on application |
| Surface Treatment / Coating | Bare titanium, MMO‑coated (Ru–Ir, Ir–Ta, etc.), platinum‑coated, mixed noble metal oxide or other catalytic coatings as per electrochemical requirements |
| Hole / Slot / Mesh Design | Can be made with different mesh patterns, hole sizes, slot designs, and flow‑through structures to optimize current distribution and mass transfer |
| Corrosion Resistance | Outstanding corrosion resistance in seawater, chloride media, many acids/alkalis, and electrochemical environments (especially with MMO/Pt coatings) |
| Mechanical Strength | High specific strength, good toughness and fatigue resistance, with sufficient rigidity for framed or unsupported mesh electrodes |
| Operating Temperature | Typically up to 260–300 ℃ in most coated applications; higher limits depending on coating system and environment |
| Surface Flatness | Low overpotential and high current efficiency when coated; stable potential and long service life under continuous operation |
| Application Range | Widely used in chlor‑alkali cells, sodium hypochlorite and ozone generators, cathodic protection, electro‑winning, electroplating/electropolishing, wastewater and seawater treatment, electrochemical disinfection, fuel cells, and various lab & pilot electrolysis systems |
| Customization | Logo, marking, frame welding, tabs and busbars, edge treatment, mesh pattern, coating type and loading, and complete electrode assemblies can all be customized according to drawings or samples |
الأبعاد المرجعية
| 0.1mm*5mm*10mm | 0.2mm*5mm*10mm | 0.1mm*10mm*20mm |
| 0.2mm*20mm*20mm | 0.3mm*20mm*30mm | 0.1mm*20mm*50mm |
| 0.2mm*30mm*100mm | 0.1to 0.5mm*50mm*50mm | يمكن تخصيص الحجم |
