Custom Titanium Mesh Electrode
Introducción
- Titanium mesh electrodes have many outstanding properties. They can be widely used in chlor-alkali production, sodium hypochlorite and ozone generation, electroplating and electrolysis, cathodic protection, electro-winning of non‑ferrous metals, wastewater and seawater treatment, electrochemical disinfection, fuel cells, electrolysis water for hydrogen, and various laboratory and pilot test systems. They are suitable for both compact cell designs and large-scale continuous production lines.
-
They offer very high corrosion resistance in acid, alkali, and saline environments, low weight, good electrical conductivity when properly coated, excellent mechanical strength, and stable electrochemical performance with long service life. Titanium mesh electrodes are easy to cut, bend, weld, and frame, making them ideal for customized shapes and structures. With MMO (mixed metal oxide), platinum, iridium–ruthenium or other catalytic coatings, they provide low overpotential, high current efficiency, and energy savings. Titanium is biocompatible, recyclable, and non‑toxic, making titanium mesh electrodes a reliable and cost‑effective choice for demanding industrial and environmental applications.
Especificaciones
| Tipo | Titanium mesh electrode |
| Material Grade | Gr1 / Gr2 / Gr7 / Gr9 titanium, other grades on request |
| Pureza | ≥99.99% |
| Formulario | Expanded mesh, perforated mesh, woven wire mesh; supplied as flat sheet, panel, or roll |
| Espesor | Mesh thickness or wire diameter customizable (typ. 0.1–1.0 mm), as per request |
| Mesh Size & Shape | Mesh opening size, strand width, and pattern fully customizable; rectangle, square, round, ring, plate, and special-shaped as per drawing |
| Surface Finish | Pickled, sandblasted, brushed, polished, or as‑rolled surface, depending on application |
| Surface Treatment / Coating | Bare titanium, MMO‑coated (Ru–Ir, Ir–Ta, etc.), platinum‑coated, mixed noble metal oxide or other catalytic coatings as per electrochemical requirements |
| Hole / Slot / Mesh Design | Can be made with different mesh patterns, hole sizes, slot designs, and flow‑through structures to optimize current distribution and mass transfer |
| Corrosion Resistance | Outstanding corrosion resistance in seawater, chloride media, many acids/alkalis, and electrochemical environments (especially with MMO/Pt coatings) |
| Mechanical Strength | High specific strength, good toughness and fatigue resistance, with sufficient rigidity for framed or unsupported mesh electrodes |
| Operating Temperature | Typically up to 260–300 ℃ in most coated applications; higher limits depending on coating system and environment |
| Surface Flatness | Low overpotential and high current efficiency when coated; stable potential and long service life under continuous operation |
| Application Range | Widely used in chlor‑alkali cells, sodium hypochlorite and ozone generators, cathodic protection, electro‑winning, electroplating/electropolishing, wastewater and seawater treatment, electrochemical disinfection, fuel cells, and various lab & pilot electrolysis systems |
| Customization | Logo, marking, frame welding, tabs and busbars, edge treatment, mesh pattern, coating type and loading, and complete electrode assemblies can all be customized according to drawings or samples |
Dimensiones de referencia
| 0.1mm*5mm*10mm | 0.2mm*5mm*10mm | 0.1mm*10mm*20mm |
| 0.2mm*20mm*20mm | 0.3mm*20mm*30mm | 0.1mm*20mm*50mm |
| 0.2mm*30mm*100mm | 0.1to 0.5mm*50mm*50mm | El tamaño se puede personalizar. |
To customize various metal electrodes, please click the picture below for details：
 |
 |
 |
 |
 |
 |
 |
 |
