Custom Aluminum Sheet Electrodes
Introduction
- Our Aluminum Sheet Electrodes are designed for applications that demand a perfect balance of high conductivity, low weight, and excellent corrosion resistance. Manufactured from high-quality aluminum with low impurity content, these electrodes offer uniform thickness, smooth surfaces, and stable electrical performance, making them ideal for electrochemical experiments, sensor development, battery and fuel cell research, and plating processes. The sheets can be easily cut, bent, or punched to match different cell designs or fixtures, allowing maximum flexibility for both laboratory and industrial users.
-
Each aluminum sheet electrode is produced under strict quality control to ensure consistent dimensions, surface cleanliness, and reliable mechanical strength. The material composition is optimized to minimize side reactions and noise during electrochemical testing, providing clear and repeatable data. Customization in size, thickness, surface treatment (polished, brushed, or pre-cleaned), and packaging is available to meet your specific project or production needs. Whether you are building prototype electrochemical cells, conducting corrosion studies, or scaling up to small-batch production, our Aluminum Sheet Electrodes deliver a cost-effective, ready-to-use solution that helps your products reach the market faster.
Specifications
| Type | Aluminum Sheet / Plate / Disc Electrode |
| Material Grade | High-purity wrought aluminum (e.g., 1050, 1060, 1100, 3003, 5052, 6061); other aluminum alloys available on request |
| Purity | Typically ≥99.9% Al for high-purity grades (depending on alloy and application requirements) |
| Form | Flat sheet, plate, disc, strip, or foil; supplied as single pieces, matched sets, or bulk batches |
| Thickness | Customizable (typically 0.01–20 mm or as requested) |
| Size & Shape | Fully customizable length, width, and diameter; rectangular, square, circular (disc), ring, and CNC‑machined special shapes per drawing |
| Surface Finish | Mill finish, bright, brushed, mirror‑polished, matte, or lightly textured to increase effective surface area |
| Surface Treatment / Coating | Bare aluminum, anodized surface, chemically cleaned/etched, conductive coatings (e.g., carbon layer) available on request |
| Hole / Slot / Mesh Design | Precision drilled or punched holes, slots, notches, perforated patterns, or expanded‑mesh structures to improve electrolyte flow and CDA |
| Corrosion Resistance | Good corrosion resistance in many neutral and slightly alkaline solutions; optional surface treatment to improve durability in harsh media |
| Mechanical Strength | High strength‑to‑weight ratio; excellent formability and ductility; suitable for cutting, bending, punching, and light welding |
| Operating Temperature | Stable performance in typical electrochemical conditions; generally suitable up to about 200–300 °C depending on alloy and environment |
| Surface Flatness | Tight tolerances on thickness and flatness to ensure uniform contact resistance and consistent current distribution |
| Application Range | Used in battery and supercapacitor research, current collectors, sensor electrodes, electrolytic cells, corrosion studies, and teaching |
| Customization | Full support for laser/water‑jet cutting, CNC machining, bending, stamping, tab welding, and complete electrode assemblies per drawings |
Reference dimensions
| 0.1mm*5mm*10mm | 0.2mm*5mm*10mm | 0.1mm*10mm*20mm |
| 0.2mm*20mm*20mm | 0.3mm*20mm*30mm | 0.1mm*20mm*50mm |
| 0.2mm*30mm*100mm | 0.1to 0.5mm*50mm*50mm | The size can be customized |
To customize various metal electrodes, please click the picture below for details：
 |
 |
 |
 |
 |
 |
 |
 |
