Laboratory Open Cell Nickel Metal Foam Sheet
Introduction
Ni Foam product is composed by pure Nickel. Product shows excellent properties of corrosion resistance and hardness.
Usefulness: (Various shapes can be produced)
- Used as the base plate/substrateofpositive electrode in Ni-MH / Ni-Cd battery, Supercapacitor.
- Filtration materials of air / oil / smoke etc.
- Porous electrode in Galvano-Chemistry Engineering.
- Elimination of heat.
- Amortization materials.
- Noise-Absorbing and Vibration-Absorbing materials.
- Electromagnetic shielding materials.
- Catalyst carrier.
- Precious metal recovery.
Specifications
| Type | Open cell |
| Purity | > 99.99% |
| Form | Sheet or Roll, depending on size & thickness |
| Cell Size (PPI) | 5-1300PPI, as per request |
| Thickness | Standard: 0.08-30mm |
| Size & Shape | Standard: 500*500mm/ 200*300mm; can be made in different shape as per request |
| Porosity | 95%-98% |
| Open Cell Rate | ≥98 % |
| Volume Density | >0.1g/cm3, as per request |
| Surface Density | 200-3500 g/m 2, as per request
Standard: 320±20g/m2 |
| Thermal Conductivity (Theoretical) | >3W/M.K |
| Mechanical Strength (Theoretical) | ≥2~7MPa |
| Average Tensile Strength (N/20mm) | Vertical ≥ 30, horizontal ≥ 25 |
| Temperature Resistance (Theoretical) | ≥500℃,as per request |
| Appearance | Silver gray, without defects such as black spots, blind holes, through holes, cracks, etc |
| Chemical Composition | Ni: ≥99.5% Fe≤0.020% C≤0.030% P≤0.010% S≤0.008% Si≤0.005% Cu≤0.010% |
| Shielding Effectiveness | 200KHz |
| 40dB~50dB | |
| Flexibility | Vertical ≥ 5, horizontal ≥ 15 |
| Elongation rate (%) | Vertical ≥ 5, horizontal ≥ 10 |
| Electrical resistivity (m Ω/100 * 10m2) | Vertical ≤ 65, horizontal ≤85 |
Reference dimensions
| 0.08mm*300mm*200mm | 0.2mm*200mm*300mm | 0.3mm*200mm*300mm |
| 0.5mm*200mm*300mm | 0.7mm*200mm*300mm | 0.9mm*200mm*300mm |
| 1.0mm*200mm*300mm | 1.3mm*200mm*300mm | 1.5mm*200mm*300mm |
| 1.7mm*200mm*300mm | 2.0mm*200mm*300mm | 5mm*200mm*300mm |
| 10mm*200mm*300mm | 30mm*200mm*300mm | The size can be customized |
